Atlas EnergyShield Ref Foil Faced 2 Sides Polyiso Insulation - All Sizes
Atlas EnergyShield Ref Foil Faced 2 Sides Polyiso Insulation - All Sizes
SKU:AES.625481P
Est Delivery between 6th Feb and
12th Feb.
How much will I need?
How much will I need?
We recommend adding 10% of additional product to the calculation to account for errors, damages, and obstacles in your project
Couldn't load pickup availability
Product Information
| Thickness | Sq/Ft Per Pallet | Sheets Per Pallet | R Value |
| 0.5 In | 1408 | 44 | R-3.3 |
| 0.625 In | 1152 | 36 | R-4.1 |
| 0.75 In | 960 | 30 | R-5 |
| 1 In | 736 | 23 | R-6.5 |
| 1.5 In | 992 | 31 | R-9.8 |
| 1.6 In | 928 | 29 | R-10.5 |
| 2 In | 736 | 23 | R-13.1 |
| 2.5 In | 608 | 19 | R-16 |
| 3 In | 480 | 15 | R-19.7 |
| 3.3 In | 480 | 15 | R-21.2 |
| 3.5 In | 416 | 13 | R-22.2 |
| 4 In | 352 | 11 | R-26 |
The Atlas EnergyShield Ref Foil Faced 2 Sides Polyiso Insulation provides superior thermal performance and energy efficiency for a wide range of construction applications, both residential and commercial. This versatile insulation solution is designed for use in multiple configurations including interior and exterior walls, attics, crawlspaces, and masonry or concrete wall systems. It's particularly effective when employed as continuous insulation over wood or gypsum sheathings and can also be used to enhance energy efficiency when retrofitted over existing cladding. This product’s adaptability makes it an essential component in modern building, ensuring compliance with various local building codes.
Manufactured with dual-sided foil facing, Atlas EnergyShield offers enhanced reflective properties which contribute to its high thermal resistance and moisture management capabilities. It is an excellent choice for projects requiring a robust insulation that can withstand extreme temperatures ranging from -100°F to +250°F. The insulation’s ability to function as an air barrier material when thicker than 1/2 inch, as prescribed by IECC and ASHRAE 90.1, further elevates its utility in creating energy-efficient spaces. Moreover, its low flame spread and smoke development ratings per ASTM E84 standards ensure safety in the event of a fire, providing peace of mind for builders and occupants alike.
Key Features:
- Versatile Application: Suitable for interior and exterior use in residential and commercial buildings. Ideal for walls, attics, crawlspaces, and more.
- High Thermal Efficiency: Foil faced on both sides to reflect heat, effectively reducing energy costs.
- Safety Compliant: Meets ASTM E84 for flame spread and smoke development, ensuring safety and compliance with building codes.
- Moisture Resistance: Minimal water absorption and classified as a Class I vapor retarder, which protects structures against dampness.
- Temperature Resilience: Can withstand extreme temperatures from -100°F to +250°F, making it suitable for diverse climates and conditions.
- Air Barrier Material: Qualifies as an air barrier when used in thicknesses greater than 1/2 inch, supporting energy conservation efforts.
Pros & Cons
Pros- Highly versatile and adaptable, suitable for a wide range of applications in both residential and commercial buildings.
- Provides superior thermal performance and energy efficiency, helping to reduce energy costs.
- Manufactured with dual-sided foil facing for enhanced reflective properties and moisture management.
- Compliant with safety standards, including ASTM E84 for flame spread and smoke development.
- Can withstand extreme temperatures, making it suitable for diverse climates and conditions.
- Functions as an air barrier material when used in thicknesses greater than 1/2 inch, supporting energy conservation efforts.
- May require professional installation due to its specific application requirements.
- May not be the most cost-effective insulation option on the market.
- Its effectiveness as an air barrier is dependent on the thickness of the application, which may limit its use in some scenarios.
Frequently Asked Questions
This insulation solution is designed for use in a wide range of construction applications, both residential and commercial. It can be used in interior and exterior walls, attics, crawlspaces, and masonry or concrete wall systems. It is particularly effective when employed as continuous insulation over wood or gypsum sheathings and can also be used to enhance energy efficiency when retrofitted over existing cladding.
The key features include its versatility in application, high thermal efficiency, compliance with safety standards, moisture resistance, temperature resilience, and its ability to function as an air barrier material when used in thicknesses greater than 1/2 inch.
This insulation is manufactured with dual-sided foil facing which offers enhanced reflective properties contributing to its high thermal resistance. It is an excellent choice for projects requiring robust insulation that can withstand extreme temperatures ranging from -100°F to +250°F.
Yes, it meets ASTM E84 standards for flame spread and smoke development, ensuring safety and compliance with building codes.
Yes, it qualifies as an air barrier material when used in thicknesses greater than 1/2 inch, as prescribed by IECC and ASHRAE 90.1, supporting energy conservation efforts.
Yes, it has minimal water absorption and is classified as a Class I vapor retarder, which protects structures against dampness.
Technical Specifications
| Brand | Atlas |
