Hunter Panels XCI Ply Class A (3/4 Ply Attached) 4ft x 8ft - All Sizes Insulation
Hunter Panels XCI Ply Class A (3/4 Ply Attached) 4ft x 8ft - All Sizes Insulation
  • Load image into Gallery viewer, Hunter Panels XCI Ply Class A (3/4 Ply Attached) 4ft x 8ft - All Sizes Insulation
  • Load image into Gallery viewer, Hunter Panels XCI Ply Class A (3/4 Ply Attached) 4ft x 8ft - All Sizes Insulation
HUNTER PANELS

Hunter Panels XCI Ply Class A (3/4 Ply Attached) 4ft x 8ft - All Sizes

This product is a call to inquire product. Please call us on 786-224-0029 for more information.
The option you have currently selected is a call to inquire option. Please call us on 786-224-0029 for more information or select an alternative option.
Regular price
$0.00
Sale price
$0.00
Regular price
Sold out
Unit price
per
+
HUNTER PANELS

Hunter Panels XCI Ply Class A (3/4 Ply Attached) 4ft x 8ft - All Sizes

Product Code: HXCI1.7

Xci Ply is an energy efficient rigid insulation panel composed of a closed cell polyisocyanurate foam core bonded to a premium performance coated glass facer on one side and ¾" fire treated plywood on the other. It is designed for use in commercial wall applications to provide both continuous insulation and a cladding attachment substrate within the building envelope.

Thickness R-Value Sq Ft/Pallet Sheets Per Pallet
1.7" 7
896
28
2.2" 10
672
21
2.7" 13.1
544
17
3.2" 16.3
480
15
3.7" 19.5 384
12
4.2" 22.7
352
11

Features and Benefits

  • Polyiso offers increased R-value per inch vs mineral fiber, XPS or EPS options
  • Designed for use in continuous insulation to assist in meeting the most current ASHRAE 90.1, IECC, IBC and IRC standards
  • A superior combination of high insulating properties and mechanically attachable surface
  • Provides improved dimensional stability and fire performance
  • Manufactured with NexGen Chemistry: Zero Ozone Depleting Potential (ODP); Contains no CFCs, HCFCs or HFCs; Virtually zero Global Warming Potential (GWP). Use of Xci products helps reduce the carbon footprint of buildings.
  • Incorporates APA-TECO Rated Exposure 1 Fire Treated Plywood with flame spread of <25 per ASTM E84
  • Approved component of the Xci AEGIS Wall System
Brand Hunter Panels
Material type Polyiso
Product length 96"
Product type Rigid Board
Product width 48"

For information on delivery costs and more click here.


Description

Xci Ply is an energy efficient rigid insulation panel composed of a closed cell polyisocyanurate foam core bonded to a premium performance coated glass facer on one side and ¾" fire treated plywood on the other. It is designed for use in commercial wall applications to provide both continuous insulation and a cladding attachment substrate within the building envelope.

Thickness R-Value Sq Ft/Pallet Sheets Per Pallet
1.7" 7
896
28
2.2" 10
672
21
2.7" 13.1
544
17
3.2" 16.3
480
15
3.7" 19.5 384
12
4.2" 22.7
352
11

Features and Benefits

  • Polyiso offers increased R-value per inch vs mineral fiber, XPS or EPS options
  • Designed for use in continuous insulation to assist in meeting the most current ASHRAE 90.1, IECC, IBC and IRC standards
  • A superior combination of high insulating properties and mechanically attachable surface
  • Provides improved dimensional stability and fire performance
  • Manufactured with NexGen Chemistry: Zero Ozone Depleting Potential (ODP); Contains no CFCs, HCFCs or HFCs; Virtually zero Global Warming Potential (GWP). Use of Xci products helps reduce the carbon footprint of buildings.
  • Incorporates APA-TECO Rated Exposure 1 Fire Treated Plywood with flame spread of <25 per ASTM E84
  • Approved component of the Xci AEGIS Wall System


Technical Specifications

Brand Hunter Panels
Material type Polyiso
Product length 96"
Product type Rigid Board
Product width 48"
